10mm "Red in Colour" Power Cable - Sold Per 100 Meter Roll
10mm "Red in Colour" Power Cable - Sold Per 100 Meter Roll
Couldn't load pickup availability
As per photos
10mm "Red in Colour" Power Cable - Power Wire
Sold and priced Per Roll 100 Meter's (Please note we do sell per meter)
Due to cost, size and weight of our high quality copper wire, Please note this is heavy in weight. Please ask for a shipping quote.
784/.2 (25.0mmsq) Plain Copper Wire V90HT PVC Sheathed
0.6/1KV single-core to AS/NZS 5000.1 with flexible conductor.
Construction
Conductor: 784 strands of 0.2mm Plain Annealed Copper to AS/NZS 1125 drawn from Class 110A copper to AS/NZS 1574.
Max. D.C. resistance at 20C: 0.78 ohms / klm.
Insulation: Coloured P.V.C. type V90HT to AS/NZS 3808.
Nominal Diameter: 8.8 mm.
Nominal Wall Thickness: 1.2 mm.
Identification: Embossed at intervals not exceeding 500mm – “TYCAB 25MM2 V90HT ELECTRIC CABLE 0.6/1KV”
Amp rating @ 30°C: 125
Electrical characteristics
Voltage Drop Single Phase: 1.78
Voltage Drop Three Phase: 1.54
Reference Standards:
AS/NZS 1125 Max. conductor Resistance.
AS/NZS 3808 PVC compound type.
AS/NZS 5000.1 Construction to 0.6/1KV UNPROTECTED type.
AS/NZS 3008 Power Amp Ratings, Voltage Drop, Derating Factors.
Due to the size and/or weight of this item, we recommend pickup whenever possible.
If you would like a quote on shipping, please contact us at RadioAndMore1@gmail.com
In your message, please don't forget to include:-
• The product(s) you’re interested in shipping
• Your full shipping address
• A contact phone number
Thank you!
10mm, Power Cable, Copper Cable, DC Power Cable, Heavy Duty Power Cable
